吸引管 Attraction tube

友情提示： 为达到产品样式最佳展现效果请切换电脑浏览器或手机横平浏览！

直形 Straight form

					B-009-XG	-D
						-Z
						-X
前弯Forward bending


	B-010-XG	-D1	B-010-XG	-D2	B-010-XG	-D3
		-Z1		-Z2		-Z3
		-X1		-X2		-X3

● 适用于上颌窦探查冲吸 ● Suitable for maxillary sinus exploration and aspiration				● 适用于上颌窦后壁吸引 ● Suitable for posterior wall suction of maxillary sinus
B-010- XG-X4	● 适用于蝶窦探查及冲吸 ● Suitable for sphenoid sinus exploration and aspiration		B-010- XG-X5	● 适用于钩突顶端尾端、额周气房的剥离和刮除 ● Suitable for peeling and scraping the top, tail and perifrontal air chambers of uncinate process

● 橄榄形头部易插入、增加安全性 ● Small to large cavities reduce the probability of blockage
● 由小至大的腔道降低了堵塞机率 ● Small to large cavities reduce the probability of blockage
● 双向交叉防滑纹手柄握姿更稳定 ● Two-way cross anti-skid handle holds more stable posture
● 360°旋转接头实现更灵活的操作 ● More flexible operation of 360 degree rotary joint

产品参数 Product parameters

吸引管【鼻吸引管】 Attraction tube
型号 Model			规格 Specifications		头部 head		长度 length
					直径 diameter	角度 angle
KRT-B-009	-XG	-D	后弯	微收口	Ø4mm	0°	130/225mm
		-Z			Ø3.5mm
		-X			Ø3mm
KRT-B-010	-XG	-D1/D2/D3	前弯	橄榄头	Ø4mm	40°/80°/110°	80/195mm
		-Z1/Z2/Z3			Ø3.5mm
		-X1/X2/X3			Ø3mm
		-X4		橄榄头	Ø3mm	15°	110/225mm
		-X5		带刮除	Ø3mm	75°	80/195mm
